Drawn Type

Код

Диаметр,
мм

Длина,
мм

Размер
резьбы,
мм

Угол,
°

Макс.
размер
отверстия,
круглое,
мм

Макс.
размер
отверстия,
шестигранник,
мм

Макс.
размер
отверстия,
квадрат,
мм

R7/02

7

30

M6x0.5

16

3.5

-

-

R9/01

9

44

M8X0.5

16

5

4

3

R9/03

9

38.5

M8x0.75

16

5

4

3

R9/06

9

51

M8x0.8

30

5

4

3

R9/09

9

44

M8x0.75

16

5

4

3

R10/03

10

58

M10x0.75

12

5.5

4

3

R11/02

11

53

M10x0.75

16

7

5

4

R11/09

11

53

M10x1

16

7

5

4

R11/10

11

57

M10x0.75

16

7

5

4

R11/11

11

52.4

M10x0.75

16

7

5

4

R11/12

11

53

M10x0.80

16

7

5

4

R12/01

12

52

M12x1

30

7

5

4

R12/02

12

50

M10x0.75

16

7

5

4

R12/05

12

50

M10x0.75

16

7

5

4

R12/07

12

50

M12x1

30

7.5

6

5

R12/08

12

50

M10x0.5

30

7

5

4

R12/09

12

50

M12x1

30

7.5

6

5

R13/01

13

41.5

M12x0.75

15

8

6

5

R14/02

14

64

M13x0.75

16

8.5

7

6

R14/03

14

62

M14x1

15˚30'

8.5

7

6

R15/02

15

54

M14x1

16

10

8

7

R15/03

15

54

M14x0.75

15

8.5

7

6

R16/01

16

50

M14x1

16

10

8

7

R16/03

16

60

M14x1

30

10

8

7

R16/06

16

55

M16x1

30

10

8

7

R16/07

16

63

M14x1

15˚30'

10

8

7

R16/10

16

58

M14x1

16

10

8

7

R16/12

16

59

M14x1

16

10

8

7

R16/15

16

59

M15x1

16

11

9

8

R16/16

16

58.5

M14x1

20

10

8

7

R18/01

18

59

M16x1

30

12

10

8

R18/02

18

60

M18x1

30

13

10

9

R18/03

18

60

M18x1

30

13

10

9

R20/01

20

55

M20x1

30

14

11

9

R20/06

20

55

M20x1

30

13

11

9

R20/07

20

58

M18x1

15

13

11

9

R21/03

21

57.5

M18x1

12

14

11

9

R22/01

22

68

M19x1

16

14

11

9

R22/03

22

70

M20x1

15

15.5

13

11

R22/08

22

68

M22x1

16

16

13

11

R23/01

23

72

M22x1

16

16.5

14

11

R24/03

24

61

M24x1

30

16

13

11

R26/02

26

77

M25x1

16

20

17

14

R27/03

27

57.5

M24x1

12

18

15

12

R28/02

28

81

M25x1

30

20.5

17

14

R28/04

28

82

M25x1

16

20.5

17

14

R28/05

28

82

M27x1

16

22

18

15

R30/01

30

70

M28x1

16

20.5

17

14

R30/02

30

85

M28x1

16

20.5

17

14

R30/04

30

59

M30x1

15

22

19

15

R30/05

30

59

M30x1

16

22

19

15

R30/06

30

68

M30x1

16

22

19

15

R30/07

30

70

M30x1

16

22

19

15

R32/02

32

71

M32x1

30

23

19

16

R32/03

32

74

M32x1

30

24

21

17

R33/01

33

70

M30x1

16

26

22

18

R34/02

34

87.5

M34x1

10

27.5

23

19

R36/02

36

89.5

M36x1

13

25

21

18

R40/03

40

72

M36x1

30

29

25

20

R40/05

40

72

M40x1

30

30

25

21

R41/01

41

54

M38x1

10

32

27

22

R41/02

41

82

M38x1

10

32

27

22

R42/01

42

82

M40x1

16

33

28

23

R42/02

42

82

M40x1

20˚30'

33

28

23

R42/04

42

82

M40x1

20

33

28

23

R44/01

44

87

M40x1

20

33

28

23

R45/01

45

82

M42x1

16

36

30

25

R46/01

46

92

M45x1

16

38

32

26

R46/02

46

82

M45x1

16

38

32

26

R48/02

48

81

M48x1.25

30

38

33

27

R48/04

48

82

M46x1

16

38

33

27

R48/06

48

81

M46x1

10

38

33

27

R50/02

50

82

M49x1

19

42

36

29
